May 29, 2000
Hitachi Releases Industry's Largest-Capacity 448-Mbyte CompactFlash(TM) and Large-Capacity 1-Gbyte PC-ATA Card
- Large capacity achieved through use of 256-Mbit flash memory stacked-mounting technology and 2-Mbyte/second high-speed programming realized -
Hitachi, Ltd. (TSE: 6501) today announced the HB288448E5  type 2 (5 mm thick)
CompactFlash(TM) *1 (CF) with the industry's largest capacity of 448 Mbytes, and the
HB2881000A5 type 2 (5 mm thick) PC-ATA card*2 with the industry's largest level
capacity of a 1-Gbyte for use as large-capacity storage media for digital cameras and
portable music players, and communication and industrial applications as a replacement
for small hard disk drives (HDDs).  Sample shipments will begin in July 2000 in Japan.

These products achieve large capacity through the use of a Double Density Package
(DDP) containing two Hitachi 256-Mbit flash memory chips.  The 448-Mbyte CF
provides 7 hours, and the 1-Gbyte PC-ATA card 16 hours, of CD-quality recording and
playback.  In addition, the maximum programming speed of 2 Mbytes/second has made it
possible to cut the programming time for large volumes of data.
The HB288320E5 320-Mbyte type 2 CF and HB288256E5 256-Mbyte type 2 CF have
also been developed concurrently, and sample shipments of these models will also begin
in July 2000 in Japan.

Recently, the use of flash cards has increased dramatically as a storage medium in
various kinds of portable devices and information products, and the rapid growth of the
market for digital cameras, portable music players, and handheld PCs, in particular, has
led to an increasing demand for CF and PC-ATA cards.  At the same time, the increasing
capacity of flash memory has brought a growing demand for its use in place of the small
HDDs previously used in the communication and industrial equipment fields.  In the
point of  its numerous advantages over former HDDs, including less system maintenance,
smaller size, lower power consumption, and excellent shock resistance, flash memory is
replacing  HDDs in the 32- to 640-Mbyte capacity range.

To meet the needs of this flash memory market, Hitachi currently offers a lineup of
8- to 192-Mbyte type 1 (3.3 mm thick) CF products and 8- to 640-Mbyte PC-ATA cards.
Hitachi has now developed the 448-/320-/256-Mbyte type 2 CF and 1-Gbyte PC-ATA
flash cards in response to the demand for even greater capacity.

These flash cards incorporate HN29W25611 256-Mbit AND-type flash memories
employing Hitachi's Multi Level Cell technology and 0.25um process.  A 512-Mbit
capacity is provided through the use of a DDP (Double Density Package) containing two
stacked HN29W25611 256-Mbit flash memory chips, enabling a PC-ATA capacity of 1
Gbyte to be achieved by incorporating 16 of these packages.  Also, to increase CF
capacity, a new 5.0 mm thick type 2 cards standard has been formulated by the CFA
(CompactFlash? Association), as opposed to the previous 3.3 mm thick type 1 cards,
enabling the industry's largest CF capacity of 448 Mbytes to be achieved by incorporating
seven of the 512-Mbit capacity Double Density Packages described above.

The same Hitachi AND-type flash memory controller as used with previous products
implements interleaved operation of multiple chips, enabling a maximum programming
speed of 2-Mbyte/second to be achieved.  This makes it possible to cut the programming
time for large volumes of data.
Future plans include the development of even larger-capacity flash memories, together
with large-capacity flash cards incorporating these memories and new flash memory
application products.

Notes:	1. CompactFlash is a trademark of SanDisk Corporation of the USA, and is licensed to
           the CFA (CompactFlash(TM) Association).  Hitachi is a member of the CFA.
	2. PC-ATA: PC card ATA specifications.  The ATA (Advanced Technology Attachment)
           specifications within the card specifications formulated by the PCMCIA (Personal
           Computer Memory Card International Association).

< Applications >
External storage devices for industrial and communication applications
Portable information devices, including handheld PCs and PDAs
Solid-state recorders
Digital cameras and camcorders

< Prices in Japan >
Part Number                                 Capacity            Sample Price
   Type 2            HB288448E5             448-Mbytes           Open price
CompactFlash(TM)     HB288320E5             320-Mbytes
                     HB288256E5             256-Mbytes
PC-ATA card          HB2881000A5            1-Gbyte              Open price

ItemCompactFlash type2
PC-ATA card
PC Card Standard ATA True-IDE Mode
Operating voltage3.3V±5% / 5V±10%
2-Mbyte/sec.(max.)(6-chip interleave)
External power
supply voltage
at 3.3Vat 5Vat 3.3Vat 5V
Sleep (typ.)0.5mA1mA0.5mA1mA
Read (typ.)25mA40mA25mA40mA
Write (typ.)25mA45mA25mA45mA
PackagesCompactFlash specification
42.8 x 36.4 x 5.0 mm3
PC Card Standard (type2) specification
54.0 x 85.6 x 5.0 mm3

* CompactFlash(TM): CompactFlash is a trademark of SanDisk Corporation and is licensed to
  the CFA (CompactFlash(TM) Association).  Hitachi is a member of the CFA
